Rohde & Schwarz CMU 200 User Manual

RF Measurements CMU
1100.4903.12 6.32 E-10
Subsystem RFANalyzer:CONTrol
The subsystem RFANalyzer:CONTrol defines the repetition mode of the RF analyzer. This subsystem
has no equivalent in manual control.
CONFigure:RFANalyzer:CONTrol:REPetition <Repetition> ,<StopCondition>,<Stepmode>
Test cycles
<Repetition>
Parameter description Def. value Def. unit
CONTinuous |
SINGleshot |
1 to 10000
Continuous measurement (until STOP or ABORT)
Single shot measurement (until Status = RDY)
Multiple measurement
(counting, until Status = STEP | RDY)
SING –
<StopCondition>
Parameter description Def. value Def. unit
NONE Continue measurement even in case of error NONE –
<Stepmode>
Description of parameters Def. value Def. unit FW vers.
STEP |
NONE
Interrupt measurement after each statistics cycle
Continue measurement according to its rep. mode
NONE – V1.15
Command description
This command determines the number of statistics cycles and the stepping mode for the measurement. A stop
condition is not available.
Note: In the case of READ commands (READ: to ) the <Repetition> parameter has no effect; the measure-
ment is always stopped after a single shot.
CONFigure:RFANalyzer:POWer:RTIMe <Time> Duration of power measurement
<Time>
Parameter description Def. value Def. unit FW vers.
0 to 1 Duration of measurement. Accuracy: ± 5E-10 s 20E-3 s V1.15
Command description
This command defines the time period during which the peak power is determined. With the time 0, the power is
immediately measured on the measurement start, i.e. the instantaneous value is measured.
Results – Subsystem RFANalyzer:POWer?
The subsystem RFANalyzer:POWer starts the analyzer power measurement and returns the results.
The subsystem corresponds to the Analyzer Power panel in the Analyzer/Generator menu.
Scalar measurement results:
READ[:SCALar]:RFANalyzer:POWer? Start single shot measurement and return results
FETCh[:SCALar]:RFANalyzer:POWer? Read out measurement results (unsynchronized)
SAMPle[:SCALar]:RFANalyzer:POWer? Read out measurement results (synchronized)
Returned value
Description Def. value Default unit FW vers.
–120.0 dBm to 47.0 dBm RMS power of the RF input signal NAN dBm V1.15
Command description
These commands are always queries. They start a measurement and return the scalar measurement result.
