CMU Audio Generator and Analyzer (with Option CMU-B41)
1100.4903.12 6.77 E-10
CONFigure:MULTitone:AF1Channel:RMODe <Reference> Result
CONFigure:MULTitone:AF2Channel:RMODe <Reference>
<Reference>
Description of parameters Def. value Def. unit FW vers.
RLEV |
TON<nr>
Results relative to the reference level
Results relative to level at test tone
<nr>, where <nr> = 1 to 20
TON4
– V3.0
Description of command
This command defines the reference value for the results of the Multitone measurement. The reference level is
defined via CONFigure:MULTitone:AF1Channel:RLEVel. To choose one of the test tones no. 1 to 20, it
must be enabled via the CONFigure:MULTitone:AF1Channel:
TDEFinition:TONE<nr> command.
CONFigure:MULTitone:AF1Channel:AFGLead <Time> AF Generator Lead
CONFigure:MULTitone:AF2Channel:AFGLead <Time>
<Time>
Description of parameters Def. value Def. unit FW vers.
0 s to 0.1 s Hold off time 0.014 s V3.0
Description of command
This command defines a hold off time for the AF generator.
Test Configuration
The commands of the following subsystems configure the Multitone measurement. They correspond to
the Multitone Configuration menu.
Subsystem MULTitone:...CONTrol
The subsystem MULTitone:...CONTrol defines the scope of the measurement. It corresponds to the
Control tab in the popup menu Multitone Configuration.
CONFigure:MULTitone:AF1Channel:CONTrol:REPetition Test Cycles
CONFigure:MULTitone:AF2Channel:CONTrol:REPetition
<Repetition>, <StopCond>, <Stepmode>
<Repetition>
Description of parameters Def. value Def. unit
CONTinuous |
SINGleshot |
1 to 1000,
Continuous measurement (until STOP or ABORT)
Single shot measurement (until Status = RDY)
Multiple measurement
(counting, until Status = STEP | RDY)
SING –
<StopCond>
Description of parameters Def. value Def. unit
SONerror |
NONE,
Stop measurement in case of error (stop on error)
Continue measurement even in case of error
NONE –
