Tolerance values – Subsystem MULTitone:...LIMit
The subsystem MULTitone:...LIMit defines tolerance values for the Multitone measurement. The sub-
system corresponds to the Limits tab of the popup menu Multitone Configuration.
CONFigure:MULTitone:AF1Channel:LIMit:LINE:ASYMmetric:UPPer
CONFigure:MULTitone:AF2Channel:LIMit:LINE:ASYMmetric:UPPer
<Limit_1>, <Enable_1>, ... <Limit_20>, <Enable_20> Upper Limit, Overall
<Limit_nr>
Description of parameters Def. value Def. unit
–80 dB to +80 dB, Upper limit line at tone <nr> See below dB
<Enable_nr>
Description of parameters Def. value Def. unit FW vers.
ON | OFF Enable upper limit line at tone <nr> ON – V3.0
Description of command
This command configures the upper limit lines and enables the limit check at the 20 test tones that can be de-
fined via CONFigure:MULTitone:AF1Channel:TONE<nr>.
By default, the limit check is switched on at all tones and the following limit lines apply:
Tone <nr> Limit Line/[dB] Enable Tone <nr> Limit Line/[dB] Enable
1 –9.5 ON 11 +5.6 ON
2 –6.2 ON 12 +6.3 ON
3 –3.8 ON 13 +6.9 ON
4 –1.9 ON 14 +7.5 ON
5 –0.3 ON 15 +8.0 ON
6 +1.0 ON 16 +8.6 ON
7 +2.1 ON 17 +9.1 ON
8 +3.1 ON 18 +9.6 ON
9 +4.0 ON 19 +10.0 ON
10 +4.8 ON 20 +10.5 ON
CONFigure:MULTitone:AF1Channel:TONE<nr>:LIMit:LINE:ASYMmetric:UPPer
CONFigure:MULTitone:AF2Channel:TONE<nr>:LIMit:LINE:ASYMmetric:UPPer
<Limit>, <Enable> Upper Limit, Single Point
<Limit>
Description of parameters Def. value Def. unit
–80 dB to +80 dB, Upper limit line at tone <nr> See below dB
<Enable>
Description of parameters Def. value Def. unit FW vers.
ON | OFF Enable upper limit line at tone <nr> ON – V3.0
Description of command
This command configures the upper limit and enables the limit check at one of 20 test tones that can be defined
via CONFigure:MULTitone:AF1Channel:TONE<nr>. The test tones are numbered by <nr> = 1 to 20. The
default limits at all test points are quoted in the previous command.
