CMU RF Measurements
1100.4903.12 6.57 E-10
WPOWer
The subsystem WPOWer measures the power of the signal transmitted by the mobile phone over a
wide frequency range. It corresponds to the softkey Pow. Meter Wideband in the RF connector tab of
the Connect. Control menu.
INITiate:WPOWer Start new measure ment ⇒ RUN
ABORt:WPOWer Abort measurement and switch off ⇒ OFF
STOP:WPOWer Stop measurement ⇒ STOP
CONTinue:WPOWer Next measurement step (only counting mode) ⇒ RUN
Description of command FW vers.
These commands have no query form. They start or stop the measurement, setting it to the status
given in the top right column.
V3.10
CONFigure:WPOWer:EREPorting <Mode> Event Reporting
<Mode> Description of parameters Def. value Def. unit FW vers.
SRQ |
SOPC |
SRSQ |
OFF
Service request
Single operation complete
SRQ and SOPC
No reporting
OFF – V3.10
Description of command
This command defines the events generated when the measurement is terminated or stopped (event reporting,
see Chapter 5).
FETCh:WPOWer:STATus? Measurement
Return
Description of parameters Def. value Def. unit FW vers.
OFF |
RUN |
STOP |
ERR |
STEP |
RDY,
1 ... 10000 |
NONE
Measurement in the OFF state (*RST or ABORt)
Running (after INITiate, CONTinue or READ)
Stopped (STOP)
OFF (could not be started)
Stepping mode (<stepmode>=STEP)
Stopped according to repetition mode and stop condition
Counter for current statistics cycle
No counting mode set
OFF
NONE
–
–
V3.10
Description of command
This command is always a query. It returns the status of the measurement (see chapters 3 and 5 of CMU operat-
ing manual).
