RF Measurements CMU
1100.4903.12 6.46 E-10
Subsystem POWer:FREQuency (Frequency/RBW)
The subsystem POWer:FREQuency sets the frequency and resolution bandwidth of the Power meas-
urement. The subsystem corresponds to the Analyzer Settings softkey in the graphical measurement
menu Power.
[SENSe:]POWer:FREQuency:CENTer <Frequency> Frequency
<Frequency>
Parameter description Def. value Default unit FW vers.
10 kHz to 2.7 GHz Frequency (0.1 Hz resolution) 1000 MHz Hz V1.15
Command description
This command defines the input frequency of the analyzer.
[SENSe:]POWer:FREQuency:BANDwidth[:RESolution] <Bandwidth>
[SENSe:]POWer:FREQuency:BWIDth[:RESolution] <Bandwidth> RBW
<Bandwidth>
Parameter description Def. value Default unit FW vers.
10 Hz to 1 MHz Bandwidths of power measurement (the values
are rounded in the steps 1 | 2 | 3 | 5)
300 kHz – V1.15
Command description
This command defines the bandwidth of the power measurement.
Subsystem POWer:LEVel (Level)
The subsystem POWer:LEVel sets the level range displayed. The subsystem corresponds to the Level
Scale hotkey in the graphical measurement menu Power.
[SENSe:]POWer:LEVel:RANGe <Range> Range
<Range>
Parameter description Def. value Default unit FW vers.
10.0 dB to 100.0 dB Level range of the power measurement 100.0 dB – V1.15
Command description
This command defines the level range of the Power measurement.
