RF Measurements CMU
1100.4903.12 6.58 E-10
CONFigure:WPOWer:CONTrol:REPetition <Repetition>,<StopCond>,<Stepmode> Test cycles
<Repetition>
Description of parameters Def. value Def. unit
CONTinuous |
SINGleshot |
1 ... 10000
Continuous measurement (until STOP or ABORT)
Single shot measurement (until Status = RDY)
Multiple measurement
(counting, until Status = STEP | RDY)
SING
–
<StopCond>
Description of parameters Def. value Def. unit
SONerror |
NONE
Start measurement in case of error (stop on error)
Continue measurement even in case of error
NONE –
<Stepmode>
Description of parameters Def. value Def. unit FW vers.
STEP |
NONE
Interrupt measurement after each statistics cycle
Continue measurement according to its rep. mode
NONE – V3.10
Description of command
This command determines the number of statistics cycles, the stop condition and the stepping mode for the
measurement.
Note: In the case of READ commands (READ:...), the <Repetition> parameter has no effect; the measure-
ment is always stopped after a single shot.
Measured Values – Subsystem WPOWer?
The subsystem WPOWer? retrieves the results of the wideband power measurement.
READ[:SCALar]:WPOWer? Start single shot measurement and return results
FETCh[:SCALar]:WPOWer?
Read out measurement results (unsynchronized)
SAMPle[:SCALar]:WPOWer?
Read out measurement results (synchronized)
Return
Description of parameters Def. value Def. unit FW vers.
0 dBm to +55 dBm
–10 dBm to +35 dBm
–35 dBm to +2 dBm
Maximum RF power at RF1
Maximum RF power at RF2
Maximum RF power at RF 4 IN
NAN dBm V3.10
Description of command
These commands are always queries. They start the measurement of the maximum RF power (peak power, not
averaged) and return the result.
