CMU RF Measurements
1100.4903.12 6.45 E-10
Test Configuration
The commands in the following subsystems configure the Power measurement. They correspond to the
Power Configuration popup menu.
Subsystem POWer:CONTrol (Control)
The subsystem POWer:CONTrol defines the scope of the Power measurement. The subsystem corre-
sponds to the Control tab of the Power Configuration menu.
CONFigure:POWer:CONTrol <Mode> Scope of measurement
<Mode>
Desciption of parameters Def. value Def. unit
SCALar |
ARRay
Scalar values only (incl. limit matching)
Scalar measured values and arrays
ARRay –
<Statistics>
Description of parameters Def. value Def. unit FW vers.
1 to 1000 |
NONE
Number of sweeps per statistics cycle
Statistics off (equivalent to 1)
1 – ≥1.15
Description of command
This command specifies the type of measured values.
CONFigure:POWer:CONTrol:REPetition <Repetition> ,<StopCondition>,<Stepmode>
Measurement cycles
<Repetition>
Parameter description Def. value Def. unit FW vers.
CONTinuous |
SINGleshot |
1 to 10000
Continuous measurement (until STOP or ABORT)
Single shot measurement (until Status = RDY)
Multiple measurement
(counting, until Status = STEP | RDY)
SING –
<StopCondition>
Parameter description Def. value Def. unit
NONE Continue measurement even in case of error NONE –
<Stepmode>
Description of parameters Def. value Def. unit FW vers.
STEP |
NONE
Interrupt measurement after each statistics cycle
Continue measurement according to its rep. mode
NONE – V1.15
Command description
This command defines the repetition mode and the stepping mode for the measurement. A stop condition is not
available.
Note: In the case of READ commands (READ: to ) the <Repetition> parameter has no effect; the measure-
ment is always stopped after a single shot.
