Rohde & Schwarz CMU 200 - Test Tones - Subsystem Multitone

CMU Audio Generator and Analyzer (with Option CMU-B41)
1100.4903.12 6.81 E-10
DEFault:MULTitone:LIMit:LINE <Enable> Default Settings
<Enable>
Description of parameters Def. value Def. unit FW vers.
ON |
OFF
The parameters are set to their default values
Some or all parameters differ from the default values
ON – V3.0
Description of command
If used as a setting command with the parameter ON this command sets all parameters of the subsystem (includ-
ing AF1Channel and AF2Channel) to their default values (the setting OFF results in an error message). If used
as a query the command returns whether all parameters are set to their default values (ON) or not (OFF).
Test Tones – Subsystem MULTitone:...TDEFinition
The subsystem MULTitone:...TDEFinition configures the audio test signal used for the Multitone meas-
urement. The subsystem corresponds to the Tone Def. tab of the popup menu Multitone Configuration.
CONFigure:MULTitone:AF1Channel:TDEFinition Test Tones
CONFigure:MULTitone:AF2Channel:TDEFinition
<Freq_1>, <Lev_1>, <Enable_1>, ... <Freq_20>, <Lev_20>, <Enable_20>
<Freq_nr>
Description of parameters Def. value Def. unit
10 Hz to 15999 Hz, Frequency of test tone <nr> See below Hz
<Lev_nr>
Description of parameters Def. value Def. unit
1.0 µV to 5.0 V, Level at test tone <nr> See below V
0
<Enable_nr>
Description of parameters Def. value Def. unit FW vers.
ON | OFF Switch on / off test tone <nr> See below – V3.0
Description of command
This command enables and configures up to 20 test tones. The minimum frequency spacing between two tones
is 1 Hz. The sum of all test tones must not exceed the maximum AF generator level quoted in the data sheet.
The following default test tones are provided:
Tone <nr> Frequency/[Hz] Level/[V] Enable Tone <nr> Frequency/[Hz] Level/[V] Enable
1 300 0.01 ON 11 1700 0.01 ON
2 440 0.01 ON 12 1840 0.01 ON
3 580 0.01 ON 13 1980 0.01 ON
4 720 0.01 ON 14 2120 0.01 ON
5 860 0.01 ON 15 2260 0.01 ON
6 1004 0.01 ON 16 2400 0.01 ON
7 1140 0.01 ON 17 2540 0.01 ON
8 1280 0.01 ON 18 2680 0.01 ON
9 1420 0.01 ON 19 2820 0.01 ON
10 1560 0.01 ON 20 3000 0.01 ON
Note: If the level of all test tones is derived from a total level (TLEVel setting in the
CONFigure:MULTitone:AF1Channel:TDEFinition:MODE command), the individual level
settings are ignored. The <Frequency> and <Enable> parameter settings are still effec-
tive.
