Rohde & Schwarz CMU 200 - Subsystem Npower:control

RF Measurements CMU
1100.4903.12 6.60 E-10
FETCh:NPOWer:STATus? Measurement Status
Return
Description of parameters Def. value Def. unit FW vers.
OFF |
RUN |
STOP |
ERR |
STEP |
RDY,
1 to 10000 |
NONE
1 to 1000 |
NONE
Measurement in the OFF state (*RST or ABORt)
Running (after INITiate, CONTinue or READ)
Stopped (STOP)
OFF (could not be started)
Stepping mode (<stepmode>=STEP)
Stopped according to repetition mode and stop condition
Counter for current statistics cycle
No counting mode set
Counter for current evaluation period within a cycle
Statistic count set to off
OFF
NONE
NONE
–
–
–
V3.07
Description of command
This command is always a query. It returns the status of the measurement (see chapters 3 and 5 of CMU operat-
ing manual).
Subsystem NPOWer:CONTrol
The subsystem NPOWer:CONTrol defines the repetition mode, statistic count, stop condition, and step-
ping mode of the NPOWer measurement.
Scope of Measurement
CONFigure:NPOWer:CONTrol <Statistics>, <Repetition>,<StopCond>,<Stepmode>
<Statistics>
Description of parameters Def. value Def. unit
1 to 1000 |
NONE
No. of evaluation periods within a statistics cycle
Statistics off
1 –
<Repetition>
Description of parameters Def. value Def. unit
CONTinuous |
SINGleshot |
1 ... 10000
Continuous measurement (until STOP or ABORT)
Single shot measurement (until Status = RDY)
Multiple measurement
(counting, until Status = STEP | RDY)
SING –
<StopCond>
Description of parameters Def. value Def. unit
SONerror |
NONE
Start measurement in case of error (stop on error)
Continue measurement even in case of error
NONE –
<Stepmode>
Description of parameters Def. value Def. unit FW vers.
STEP |
NONE
Interrupt measurement after each statistics cycle
Continue measurement according to its rep. mode
NONE – V3.07
Description of command
This command defines the statistic count, repetition mode, stop condition, and stepping mode for the measure-
ment.
