RF Measurements CMU
1100.4903.12 6.34 E-10
FETCh:RFGenerator:STATus? Generator status
Returned value
Parameter description Def. value Def. unit FW vers.
OFF |
RUN |
ERR
Generator switched off (ABORt or *RST)
Running (INITiate)
Switched off (could not be started)
OFF
– V1.15
Command description
This command is always a query. It returns the current generator status.
Subsystem RFGenerator... (Generator Settings)
The subsystem RFGenerator... determines the level and frequency of the RF generator. It corresponds
to the input field RF Level and the Frequency softkey in the Generator panel (in Connection Control,
Generator tab and in the Analyzer/Generator menu).
SOURce:RFGenerator[:TX]:LEVel <Level> RF Level
<Level>
Parameter description Def. value Def. unit FW vers.
–137.0 to –27.0 dBm
–137.0 to –10.0 dBm
–90.0 to +13.0 dBm
RF1 level in the used timeslot
RF2 level in the used timeslot
RF 3 OUT level in the used timeslot
–27.0
–27.0
–27.0
dBm
dBm
dBm
V1.15
Command description
This command defines the RF generator level. The permissible value range depends on the used RF output of
the CMU and the external attenuation. Moreover, in the SSB mode (see command
SOURce:RFGenerator:MODulation SSB), the level ranges for all three connectors are shifted by –2 dB, and
the default value for RF1 OUT is –29.0 dBm. The level ranges are also modified if the Tx and Aux Tx signals are
both active and superimposed at the same connector.
SOURce:RFGenerator[:TX]:FREQuency <Frequency> Frequency
<Frequency>
Parameter description Def. value Def. unit FW vers.
100 kHz to 2.7 GHz
Output frequency (resolution 0.1 Hz) 1200 MHz Hz V1.15
Command description
This command defines the output frequency of the RF generator. The usable frequency range exceeds the speci-
fied range, see data sheet.
