CMU CMU Base System
1100.4903.12 6.9 E-10
Symbolic Status Event Register Evaluation
The following commands are used to retrieve the events reported and the corresponding function
groups; see section Symbolic Status Event Register Evaluation in chapter 5.
STATus:OPERation:EVENt:SADDress? Check event reporting
Response
Parameter description
Def. Value
2
Default Unit FW vers.
1 to 30,
"Fgrp"
"Next" secondary address
Corresponding function group name (or "", if no
event was reported)
31
""
–
–
V2.10
Command description
This command is always a query. It checks the STATus:OPERation: CMU:SUM<nr>:EVENt sum registers
(<nr> = 1 | 2), returns the next secondary address and function group string where an event was reported, and
deletes the entry in the EVENt register. If applied repeatedly, the command checks the secondary addresses in
ascending order (i.e. the events are not queried chronologically).
The command is global; it is available in all function groups. Possible responses are:
1,"RF_NSig" An event was reported in function group RF (currently assigned to secondary ad-
dress 1).
31,"" No (further) event reported.
STATus:OPERation:SYMBolic:ENABle <Event>{,<Event>} Symbolic status evaluation
Parameter list
Parameter description
Def. Value
3
Default Unit FW vers.
<Event>{,<Event>} |
NONE
List of symbols for events to be reported
No event reported
NONE – V2.10
Command description
This command enables event reporting for one or several events in the current function group, i.e. it sets the cor-
responding bits in the STATus:OPERation:CMU: SUM<nr>:CMU<nr_event>:ENABle register (<nr> = 1
| 2, <nr_event> denotes the current function group) and in all sum registers up to the status byte. The
events and the corresponding symbols for each function group are listed in chapter 5 of the relevant manuals
(see section Status Registers). The symbols may be entered in arbitrary order.
STATus:OPERation:SYMBolic[:EVENt]? Symbolic status evaluation
Response
Parameter description
Def. Value
4
Default Unit FW vers.
NONE |
<Event>{,<Event>}
No event in the current function group
List of reported events
NONE – V2.10
Command description
This command is always a query. It lists the events reported in the current function group and deletes these
events in the STATus:OPERation:CMU:SUM<nr> :CMU<nr_event>:EVENt register as well as in all sum
registers.
2
The default values quoted in this command are achieved after a *CLS command. *RST does not supersede the entries in the status registers; see section Reset Values of
the Status Reporting Systems in chapter 5.
3
The default values quoted in this command are achieved after a STATus:PRESet command. *RST does not supersede the entries in the status registers; see section
Reset Values of the Status Reporting Systems in chapter 5.
4
The default values quoted in this command are achieved after a *CLS command. *RST does not supersede the entries in the status registers; see section Reset Values of
the Status Reporting Systems in chapter 5.
