Rohde & Schwarz CMU 200 - Subsystem Spectrum:control; Test Configuration

RF Measurements CMU
1100.4903.12 6.52 E-10
[SENSe:]SPECtrum:DETector <Mode> Detect Mode
<Mode>
Desciption of parameters Def. value Def. unit FW vers.
PEAK |
RMS
Meas. curve interpolated from maximum values
Meas. curve interpolated from RMS averaged values
PEAK – V3.05
Description of command
This command defines how the measurement curve is calculated from the entire set of measurement points.
Test Configuration
The commands in the following subsystems configure the Spectrum measurement. They correspond to
the Spectrum Configuration popup menu.
Subsystem SPECtrum:CONTrol
The subsystem SPECtrum:CONTrol defines the scope of the spectrum measurement. It corresponds to
the tab Control in the popup menu Spectrum Configuration.
CONFigure:SPECtrum:CONTrol <Mode>, <Statistics> Scope of measurement
<Mode>
Desciption of parameters Def. value Def. unit
SCALar |
ARRay
Scalar values only (incl. limit matching)
Scalar measured values and arrays
ARRay –
<Statistics>
Description of parameters Def. value Def. unit FW vers.
1 to 1000 |
NONE
Number of sweeps per statistics cycle
Statistics off (equivalent to 1)
1 – ≥1.15
Description of command
This command specifies the type of measured values and defines the number of sweeps forming a statistics cy-
cle.
