Subsystem POWer:TIME
The subsystem POWer:TIME configures the time axis. The subsystem corresponds to the Time Scale
hotkey in the graphical measurement menu Power.
[SENSe:]POWer:TIME:DELay <Delay> Delay
<Delay>
Parameter description Def. value Default unit FW vers.
See below Delay time between trigger time and start of the
measurement
–10.0 µs s V1.15
Command description
This command defines the time when the measurement is started relative to the trigger time.
The permissible range of delays depends on the span and bandwidth, e.g.:
- 152.9 µs to 142.9 µs (bandwidth 1 MHz, span 10 µs)
- 15.7919207 s to 5.7919207 s (bandwidth 10 Hz, span 10 s )
[SENSe:]POWer:TIME:SPAN <Span> Span
<Span>
Parameter description Def. value Default unit FW vers.
10 µs to 10 s Span of the power measurement 100 µs s V1.15
Command description
This command defines the span (i.e. the total evaluation time) of the Power measurement. The permissible
spans depend on the selected bandwidth.
CONFigure:POWer:CONTrol:TIMeout <Timeout> Timeout for triggered measurements
<Timeout>
Parameter description Def. value Default unit FW vers.
1 s to 60 s Timeout period after which the measure-
ment is aborted
10 s s V1.15
Command description
This command defines a timeout period after which the measurement is aborted (e.g. if no trigger event could be
detected).
