Rohde & Schwarz CMU 200 - Status Commands

CMU Base System CMU
1100.4903.12 6.6 E-10
Status Commands
The STATus subsystem controls the SCPI-defined status reporting structures. The purpose and defini-
tion of status registers is given in chapter 5, section "Status Reporting System". Unless otherwise
stated, all the following commands are SCPI-confirmed.
STATus:OPERation[:EVENt]? Event Part
Response
Parameter description
Def. value
1
Default unit FW vers.
0 to 32767 Event part – – V1.20
Command description
This command queries and deletes the contents of the EVENt part of the STATus:OPERation register.
STATus:OPERation:ENABle <Number> Enable part
<Number>
Parameter description Def. value Default unit FW vers.
0 to 32767 Enable part – – V1.20
Command description
This command enters a number to be interpreted as a bit pattern in the ENABle part of the STATus:OPERation
register. If a bit is set the corresponding event is reported in the summary bit of the status byte.
STATus:OPERation:CMU:SUM<nr>[:EVENt]? Event part
Response
Parameter description Def. value Default unit FW vers.
0 to 32767 Event part – – V1.20
Command description
This command queries and deletes the contents of the EVENt part of the STATus:OPERation:CMU:SUM<nr>
register (<nr> = 1,2).
STATus:OPERation:CMU:SUM<nr>:ENABle <Number> Enable part
<Number>
Parameter description Def. value Default unit FW vers.
0 to 32767 Enable part – – V1.20
Command description
This command enters a number to be interpreted as a bit pattern in the ENABle part of the
STATus:OPERation:CMU:SUM<nr> register (<nr> = 1,2). If a bit is set the corresponding event is reported in the
summary bit of the status byte.
STATus:OPERation:CMU:SUM<nr>:CMU<nr_event>[:EVENt]? Event part
Response
Parameter description Def. value Default unit FW vers.
0 to 32767 Event part – – V1.20
Command description
This command queries and deletes the contents of the EVENt part of the
STATus:OPERation:CMU:SUM<nr>:CMU<nr_event> register (<nr> = 1 to 2; <nr_event> = 1 to 15).
1
*RST does not supersede the entries in the status registers; for an overview of the reset values of the STATus... system refer to section Reset Values of the Status
Reporting Systems in chapter 5.
