Audio Generator and Analyzer (with Option CMU-B41) CMU
1100.4903.12 6.80 E-10
CONFigure:MULTitone:AF1Channel:LIMit:LINE:ASYMmetric:LOWer
CONFigure:MULTitone:AF2Channel:LIMit:LINE:ASYMmetric:LOWer
<Limit_1>, <Enable_1>, ... <Limit_20>, <Enable_20> Lower Limits, Overall
<Limit_nr>
Description of parameters Def. value Def. unit
–80 dB to +80 dB, Lower limit line at tone <nr> See below dB
<Enable_nr>
Description of parameters Def. value Def. unit FW vers.
ON | OFF Enable lower limit line at tone <nr> ON – V3.0
Description of command
This command configures the lower limit lines and enables the limit check at the 20 test tones that can be defined
via CONFigure:MULTitone:AF1Channel:TONE<nr>.
By default, the limit check is switched on at all tones and the following limit lines apply:
Tone <nr> Limit Line/[dB] Enable Tone <nr> Limit Line/[dB] Enable
1 –13.5 ON 11 +1.6 ON
2 –10.2 ON 12 +2.3 ON
3 –7.8 ON 13 +2.9 ON
4 –5.9 ON 14 +3.5 ON
5 –4.3 ON 15 +4.0 ON
6 –3.0 ON 16 +4.6 ON
7 –1.9 ON 17 +5.0 ON
8 –0.9 ON 18 +5.0 ON
9 0.0 ON 19 +5.0 ON
10 +0.8 ON 20 +5.0 ON
CONFigure:MULTitone:AF1Channel:TONE<nr>:LIMit:LINE:ASYMmetric:LOWer
CONFigure:MULTitone:AF2Channel:TONE<nr>:LIMit:LINE:ASYMmetric:LOWer
<Limit>, <Enable> Lower Limit, Single Point
<Limit>
Description of parameters Def. value Def. unit
–80 dB to +80 dB, Lower limit line at tone <nr> See below dB
<Enable>
Description of parameters Def. value Def. unit FW vers.
ON | OFF Enable lower limit line at tone <nr> ON – V3.0
Description of command
This command configures the lower limit and enables the limit check at one of 20 test tones that can be defined
via CONFigure:MULTitone:AF1Channel:TONE<nr>. The test tones are numbered by <nr> = 1 to 20. The
default limits at all test points are quoted in the previous command.
DEFault:MULTitone:AF1Channel:LIMit:LINE <Enable> Default Settings
DEFault:MULTitone:AF2Channel:LIMit:LINE <Enable>
<Enable>
Description of parameters Def. value Def. unit FW vers.
ON |
OFF
The parameters are set to their default values
Some or all parameters differ from the default values
ON
– V3.0
Description of command
If used as a setting command with the parameter ON this command sets all parameters of the subsystem to their
default values (the setting OFF results in an error message).
If used as a query the command returns whether all parameters are set to their default values (ON) or not (OFF).
