Audio Generator and Analyzer (with Option CMU-B41) CMU
1100.4903.12 6.72 E-10
Bandwidth (DC Coup.)
CONFigure:AFANalyzer[:PRIMary]:FILTer:BPASs:DCCoupling <Band pass>
CONFigure:AFANalyzer:SECondary:FILTer:BPASs:DCCoupling <Band pass>
<Band pass>
Description of parameters Def. value Def. unit FW vers.
BP02 |
BP03 |
BP05 |
BP06 |
BP07 |
BP09 |
BP10 |
BP11 |
BP13 |
BP14 |
BP15 |
BP17 |
BP18
CMU band pass filter with a bandwidth of
6 Hz to 250 Hz
50 Hz to 250 Hz
6 Hz to 3000 Hz
50 Hz to 3000 Hz
300 Hz to 3000 Hz
6 Hz to 4000 Hz
50 Hz to 4000 Hz
300 Hz to 4000 Hz
6 Hz to 15000 Hz
50 Hz to 15000 Hz
300 Hz to 15000 Hz
6 Hz to 21000 Hz
50 Hz to 21000 Hz
BP17
– V3.05
Description of command
This command selects the first band pass in the AF analyzer to be used if the AF path coupling is set to DC (see
CONFigure:AFANalyzer...:COUPling command).
Note: In firmware versions
≥
V2.12 but <V3.05, the CONFigure:AFANalyzer... :FILTer:BPASs
commands replace the CONFigure:AFANalyzer... :FILTer:BPASs:ACCoupling and CON-
Figure:AFANalyzer...:FILTer: BPASs:DCCoupling commands. No distinction is made be-
tween AC and DC path coupling. In firmware V3.00, no band pass selection is possible if
DC path coupling is set. The CMU always uses a default band pass with a bandwidth of 6
Hz to 21000 Hz (BP17).
