Audio Generator and Analyzer (with Option CMU-B41) CMU
1100.4903.12 6.74 E-10
FETCh:AFGenerator[:PRIMary]:STATus? Generator Status
FETCh:AFGenerator:SECondary:STATus?
Return
Description of parameters Def. value Def. unit FW vers.
OFF |
RUN |
ERR
Generator switched off (ABORt, *RST or OFF due to
conflict of resources)
Running (INITiate)
Switched off (could not be started)
OFF
– V2.10
Description of command
This command is always a query. It returns the current generator status.
SOURce:AFGenerator[:PRIMary]:LEVel <Level> Generator Level
SOURce:AFGenerator:SECondary:LEVel <Level>
<Level>
Description of parameters Def. value Def. unit FW vers.
0 V to 5 V AF generator voltage 1 V V2.10
Description of command
This command defines the RMS voltage of the generated AC audio signal or the constant DC voltage, depending
on the selected signal type (see command SOURce:AFGenerator...SMODe).
SOURce:AFGenerator[:PRIMary]:FREQuency <Frequency> Frequency
SOURce:AFGenerator:SECondary:FREQuency <Frequency>
<Frequency>
Description of parameters Def. value Def. unit FW vers.
20 Hz to 20 kHz AF-Generator frequency 1000 Hz V2.10
Description of command
This command determines the AF generator frequency.
SOURce:AFGenerator[:PRIMary]:SMODe <Signal> Generator Signal
SOURce:AFGenerator:SECondary:SMODe <Signal>
<Frequency>
Description of parameters Def. value Def. unit FW vers.
AF | DC AF generator signal type AC – V3.10
Description of command
This command determines whether the AF generator signal is an AC or DC signal.
