RM0401

40/771 RM0401 Rev 3

APB2

0x4001 5400- 0x4001 FFFF Reserved

0x4001 5000 - 0x4001 53FF SPI5/I2S5

0x4001 4C00- 0x4001 4FFF Reserved

0x4001 4800 - 0x4001 4BFF TIM11

0x4001 4400 - 0x4001 47FF Reserved

0x4001 4000 - 0x4001 43FF TIM9

0x4001 3C00 - 0x4001 3FFF EXTI

0x4001 3800 - 0x4001 3BFF SYSCFG

0x4001 3400 - 0x4001 37FF Reserved

0x4001 3000 - 0x4001 33FF SPI1/I2S1

0x4001 2400 - 0x4001 2FF Reserved

0x4001 2000 - 0x4001 23FF ADC1

0x4001 1800 - 0x4001 1FFF Reserved

0x4001 1400 - 0x4001 17FF USART6

0x4001 1000 - 0x4001 13FF USART1

0x4001 0400 - 0x4001 0FFF Reserved

0x4001 0000 - 0x4001 03FF TIM1

Table 1. Register boundary addresses (continued)

Bus Boundary address Peripheral
