The USART peripherals operate at the internal 16 MHz oscillator (HSI) frequency.
The embedded bootloader code is located in system memory. It is programmed by ST
during production. For additional information, refer to application note AN2606.
Physical remap in STM32F410
Once the boot pins are selected, the application software can modify the memory
accessible in the code area (in this way the code can be executed through the ICode bus in
place of the System bus). This modification is performed by programming the Section 7.2.1:
SYSCFG memory remap register (SYSCFG_MEMRMP) in the SYSCFG controller.
The following memories can thus be remapped:
• Main Flash memory
• System memory
• Embedded SRAM
Table 4. Memory mapping vs. Boot mode/physical remap in STM32F410
Addresses
Boot/Remap in main
Flash memory
Boot/Remap in
embedded SRAM
Boot/Remap in
System memory
0x2000 0000 - 0x2002 7FFF SRAM (32 KB) SRAM (32KB) SRAM (32KB)
0x1FFF 0000 - 0x1FFF 77FF System memory System memory System memory
0x0802 0000 - 0x1FFE FFFF Reserved Reserved Reserved
0x0800 0000 - 0x0801 FFFF Flash memory Flash memory Flash memory
0x0400 000 - 0x07FF FFFF Reserved Reserved Reserved
0x0000 0000 - 0x0001 FFFF
(1)
1. Even when aliased in the boot memory space, the related memory is still accessible at its original memory
space.
Flash (128 KB) Aliased
SRAM1 (32 KB)
Aliased
System memory
(30 KB) Aliased
