Embedded Flash memory interface RM0401
46/771 RM0401 Rev 3
3.3 Embedded Flash memory
The Flash memory has the following main features:
Capacity up to 128 Kbytes
128 bits wide data read
Byte, half-word, word and double word write
Sector and mass erase
Memory organization
The Flash memory is organized as follows:
A main memory block divided into 4 sectors of 16 Kbytes plus 1 sector of
64 Kbytes.
System memory from which the device boots in System memory boot mode
512 OTP (one-time programmable) bytes for user data
The OTP area contains 16 additional bytes used to lock the corresponding OTP
data block.
Option bytes to configure read and write protection, BOR level, watchdog
software/hardware and reset when the device is in Standby or Stop mode.
Low-power modes (for details refer to the Power control (PWR) section of the reference
manual)
Table 5. Flash module organization
Block Name Block base addresses Size
Main memory
Sector 0 0x0800 0000 - 0x0800 3FFF 16 Kbytes
Sector 1 0x0800 4000 - 0x0800 7FFF 16 Kbytes
Sector 2 0x0800 8000 - 0x0800 BFFF 16 Kbytes
Sector 3 0x0800 C000 - 0x0800 FFFF 16 Kbytes
Sector 4 0x0801 1000 - 0x0801 FFFF 64 Kbytes
System memory 0x1FFF 0000 - 0x1FFF 77FF 30 Kbytes
OTP area 0x1FFF 7800 - 0x1FFF 7A0F 528 bytes
Option bytes 0x1FFF C000 - 0x1FFF C00F 16 bytes
