RM0401 Debug support (DBG)

762

26.17.10 Example of configuration

• Set the bit TRCENA in the Debug Exception and Monitor Control Register (DEMCR)

• Write the TPIU Current Port Size Register to the desired value (default is 0x1 for a 1-bit

port size)

• Write TPIU Formatter and Flush Control Register to 0x102 (default value)

• Write the TPIU Select Pin Protocol to select the sync or async mode. Example: 0x2 for

async NRZ mode (UART like)

• Write the DBGMCU control register to 0x20 (bit IO_TRACEN) to assign TRACE I/Os

for async mode. A TPIU Sync packet is emitted at this time (FF_FF_FF_7F)

• Configure the ITM and write the ITM Stimulus register to output a value

0xE0040304

Formatter and flush

control

Bits 31-9 = always ‘0

Bit 8 = TrigIn = always ‘1 to indicate that triggers are indicated

Bits 7-4 = always 0

Bits 3-2 = always 0

Bit 1 = EnFCont. In Sync Trace mode (Select_Pin_Protocol register

bit1:0=00), this bit is forced to ‘1: the formatter is automatically enabled

in continuous mode. In asynchronous mode (Select_Pin_Protocol

formatter.

Bit 0 = always 0

The resulting default value is 0x102

Note: In synchronous mode, because the TRACECTL pin is not mapped

outside the chip, the formatter is always enabled in continuous mode -this

way the formatter inserts some control packets to identify the source of

the trace packets).

0xE0040300

Formatter and flush

status

Not used in Cortex

-M4 with FPU, always read as 0x00000008

Table 144. Important TPIU registers (continued)

Address Register Description
