RM0401 Rev 3 471/771

RM0401 Low-power timer (LPTIM)

472

18.7.9 LPTIM1 option register (LPTIM1_OR)

Address offset: 0x020

Reset value: 0x0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. OR_1 OR_0

rw rw

Bits 31:2 Reserved, must be kept at reset value.

Bits 1:0 OR_1/0: Low-power timer input 1 remap

These bits are set and cleared by software.

00: LPTIM1 input 1 connected to PB5 (AF1) or PC0 (AF1) for timer input

01: LPTIM1 input 1 is connected to PA4, the input signal depends on the alternate function that has

been selected for PA4

10: LPTIM1 input 1 is connected to PB9, the input signal depends on the alternate function that has

been selected for PB9

11: LPTIM1 input 1 is connected to TIM6/DAC trigger
