ST STM32F410 User Manual

Debug support (DBG) RM0401
740/771 RM0401 Rev 3
26.6.4 Cortex
®
-M4 with FPU JEDEC-106 ID code
The Arm
®
Cortex
®
-M4 with FPU integrates a JEDEC-106 ID code. It is located in the 4KB
ROM table mapped on the internal PPB bus at address 0xE00F FFD0_0xE00F FFE0.
This code is accessible by the JTAG Debug Port (4 to 5 pins) or by the SW Debug Port (two
pins) or by the user software.
26.7 JTAG debug port
A standard JTAG state machine is implemented with a 4-bit instruction register (IR) and five
data registers (for full details, refer to the Cortex
®
-M4 with FPUr0p1 Technical Reference
Manual (TRM), for references, please see Section 26.2: Reference Arm® documentation).
Table 131. JTAG debug port data registers
IR(3:0) Data register Details
1111
BYPASS
[1 bit]
1110
IDCODE
[32 bits]
ID CODE
0x4BA0 0477 (Arm
®
Cortex
®
-M4 with FPU r0p1 ID Code)
1010
DPACC
[35 bits]
Debug port access register
This initiates a debug port and allows access to a debug port register.
– When transferring data IN:
Bits 34:3 = DATA[31:0] = 32-bit data to transfer for a write request
Bits 2:1 = A[3:2] = 2-bit address of a debug port register.
Bit 0 = RnW = Read request (1) or write request (0).
– When transferring data OUT:
Bits 34:3 = DATA[31:0] = 32-bit data which is read following a read
request
Bits 2:0 = ACK[2:0] = 3-bit Acknowledge:
010 = OK/FAULT
001 = WAIT
OTHER = reserved
Refer to Table 132 for a description of the A[3:2] bits

ST STM32F410 Specifications

General

Series	STM32F4
Core	ARM Cortex-M4
Max Clock Speed	100 MHz
Maximum CPU frequency	100 MHz
Program memory size	Up to 128 KB
Program memory type	Flash
SRAM	32 KB
RAM size	32 KB
GPIO Pins	Up to 50
Number of I/Os	Up to 50
ADC Channels	Up to 10
ADC	12-bit
DAC Channels	1
Timers	6
Communication Interfaces	I2C, SPI, USART, USB
Operating voltage	1.7 V to 3.6 V
Operating Temperature	-40°C to 85°C
Package	LQFP64
