• To select a function to display when the enlarged middle row display is in use:
• Press the symbol side of the display change-over switch to browse for
the functions in forward order.
• Press the side of the display change-over switch opposite to the symbol
to browse for the functions in reverse order.
3.9.3 Top and middle row views
The Proline instrument panel display functions are seen on the top or the middle
row.
The top row and the middle row have the same functions. Different functions can
be displayed at the same time on both rows.
When the power is turned on, the view that was selected last is shown on the
display.
The following functions can be displayed on the top and middle rows of the display:
Symbol Function
Working time (h:mm)
Cruise control
km/h/mph Driving speed (km/h/mph)
Wheel slip (%, 0-100)
Rear power take-off (PTO) speed (rpm)
Front power take-off (PTO) speed (rpm)
Engine speed (rpm)
Immediate fuel consumption (ha, acre)
Average fuel consumption (ha, acre)
Immediate fuel consumption
Average fuel consumption
Fuel consumption
Lower link position (%, 0-100)
Lifting link position of front linkage (%, 0-100)
Sigma power (%, 0–100)
Gearbox temperature (C/F)
Travel distance (m/km/miles)
Square area (ha)
Periodical maintenance
3. Operation
- 127 -
