Valtra HiTech T3 Series User Manual

Indicator light Indication
GUID-A1E9566C-86CE-4AD3-A512-
D772AE266E1E
Engine oil pressure light
GUID-8D5CD1CF-666F-46C9-9211-2B
B777A73D4E
The exclamation mark is lit together with other indicator lights (yellow).
GUID-9DD75249-0CC3-461D-84EC-
C9937C947DB9
Glow indicator light
The light (yellow) is lit when the ignition key is in position
and the engine is cold.
Ʃ indicator light (on model T193 H)
The light is lit continuously (yellow) when the tractor is operating in the higher power
range and using PTO.
GUID-
F0C90BFB-3126-404D-8C49-3FA955C
C4FD2
Parking brake indicator light
The light (red) is lit to indicate that the power shuttle lever is in the parking brake position.
GUID-714DD8B7-ED71-4AA7-
BFAA-31C5E3693067
Low fuel level indicator light
The light is lit (yellow) and a buzzer sounds once to indicate that about 50 litres of fuel
is left.
GUID-CD4C4C77-7CDB-4FB5-AF3A-
BEFDF3417EB1
Battery charging indicator light
2.3.1.3 Indicator lights on the right side of the display
CRUISE
F
R
S
T
O
P
GUID-0465EB98-1ABC-4D9F-99B4-4EE9E99E94E7
Indicator light
Indication
STOP indicator light (red)
GUID-9B9A9C87-
BB4C-43A1-9A88-789929
9F22D0
Gearbox oil pressure light
GUID-
AC890C72-21FE-4056-89
5A-DB34A4CE9357
Gearbox oil temperature light
GUID-9B16B673-
D692-4975-
A9F9-5D6DBAFC4177
Pressure oil filter clogging indicator light
Table continued on next page
2. Instruments and controls
- 32 -
