Valtra HiTech T3 Series User Manual

2.17 Rear controls and connections outside the cab
STOP
STOP
2
4
6
11
7
12
8
9
10
11
11
15
15 16 17
8
14
5
3
9
13
GUID-4A68A574-BFB0-4375-A301-58C6F10E6532
1. Inlet, remote control cables
2. Trailer socket
3. Trailer coupling Duo-Matic (extra equipment)
4. Emergency stop plug for rear power take-off (PTO)
5. Hitch ball storing bracket
6. Top link
7. Quick-action couplings, auxiliary hydraulics
8. Lifting links
9. Pick-up hitch lifting links (extra equipment together with the pick-up hitch)
10. Levelling gear
11. Check links
12. Auxiliary hydraulic system return coupling
13. Quick-action coupling for the trailer brakes (extra equipment)
14. Hydraulic levelling ram (extra equipment)
15. Lower links
16. PTO shaft
17. Pick-up hitch (extra equipment)
The pick-up hitch is extra equipment with many alternatives.
2. Instruments and controls
- 52 -
