GUID-4958FCFB-0B02-4AE3-A231-8C8F0D00D3C3
1. Rear PTO on/off push button (extra equipment)
Sigma Power
The Sigma Power control system gives extra power for PTO work. When required
for PTO work, the engine will automatically provide up to 30 hp more power.
The Sigma Power activates automatically when the power transferred through the
PTO rises high enough. As a sign of this, the Sigma Power symbol is lit on the
instrument panel.
GUID-EE7848AE-6906-40FB-B199-0130DAD63F5A
1. Sigma Power symbol
2. When the PTO is on, the display shows (on top/centre row) how much of the
power is transferred through the PTO as a percentage.
3.17.2.1 Recommended rear power take-off shafts
Both the power take-off (PTO) nominal speeds can be used regardless of the
type of shaft installed on the tractor.
Implements for 540 rpm (at engine speed of 1 874 rpm)
Normally a 6-spline shaft (extra equipment) with a diameter of 1⅜" (35 mm) is
recommended.
3. Operation
- 195 -
