6.13.5.4 Euro trailer hitch
The horizontal distances of the pulling point from the power take-off (PTO) shaft
and the maximum vertical loadings:
54
1
2
3
10
12
11
6
7
8
13
14
9
GUID-181E62A8-760D-43B0-A292-B941C62386B9
1. 481 mm
2. 351 mm
3. 226 mm
4. 285 mm
5. 189 mm
6. Z (number of splines on PTO shaft) = 20
7. 2 mm
8. Z = 6
9. 65 mm
10. 16 kN
11. 23 kN
12. 30 kN
13. 40 mm
14. 30 kN
6.13.5.5 Euro trailer hitch with hydraulic extension
Raising/lowering and extension
Electro-hydraulic
Locking of the towing device latch Electro-hydraulic
Hitch or drawbar Replaceable
Maximum weight of the tractor 12 500 kg
Trailer hitch/jaw Lowered down to the ground when extended
The towing point distances from the take-off axle and the maximum vertical loads
in the horizontal direction are shown in the following figure.
6. Technical specifications
- 360 -
