4
3
2
AUTO
A
U
T
O
M
IN
M
A
X
P
1
1
2
3
4
5
6
7
8
9
GUID-F503AC63-1F43-4572-B4F4-23592732D1BC
1. Lowering speed selector
2. Position control knob
3. Passing switch for position control knob
4. Lift/stop/lower switch
1. Set the lift/stop/lower switch to the lower (Autocontrol) position.
2. Press down the passing switch for position control knob.
The lower links pass the limit set by the position control knob.
3. Release the passing switch for position control knob.
The lower links return to the value set by the position control knob.
3.12.13 Passing the height set by the lifting height selector
Use the passing switch for the position control knob when you temporarily need
the lower links to pass the MAX position set by the lifting height selector. This
feature is useful, for example, when disconnecting the pick-up hitch or to make
sure that the pick-up hitch latches when connecting a trailer to the tractor.
The passing switch for the position control knob is spring returned and operates
when the lift/stop/lower switch is in the lift (transport) position and the lifting
selector is in the MAX position.
3. Operation
- 164 -
