5. Press the Powershift pre-programming button.
GUID-9EB34E62-7AEA-4FF1-B593-4A85D8843710
The last two bars are lit to indicate that the parameter value is shown on the
bottom row.
6. Change the parameter value by pressing Powershift push buttons.
7. Press the Powershift pre-programming button to save the value.
You can discard the changes by pressing the HiShift push button.
8. Press the HiShift push button to leave the setting menu and save all changes.
If you want to leave the setting menu and discard all changes made, turn the
ignition switch off.
3.17.3 Front power take-off
Front power take-off (PTO) is only available with front linkage (extra equipment).
GUID-A5D4CE5C-93AE-41B9-B177-2D6473506E51
1. Oil cooler
2. Front PTO shaft
The front PTO shaft has a diameter of 35 mm with 6 splines. The front PTO is
equipped with a pump inside the housing and an oil cooler to prevent
3. Operation
- 205 -
