3
2
1
1
2
GUID-DE5DD197-1BE1-4CCD-B670-C13661931724
1. Fastening hole for working position
2. Fastening hole for floating or transport position
3. Locking pin
Lifting link position Fastening pin location
Working Fastening pins are in holes 1.
Floating Fastening pins are in holes 2.
Transport Lifting links are folded up and fastening pins are in holes 2.
• Check that the locking pins of the fastening pins are in their positions when
the lifting links are mounted.
• When driving on public roads, with or without an implement, always lift the
front linkage fully up.
• When you drive on public roads and there is an implement on the front
linkage covering the headlights, the upper headlights (extra equipment) have
to be switched on.
3.16 Using the Valtra front loader
WARNING: Check that all screws are tightened before using the front
loader.
WARNING: Always look at the implement. Objects can fall or roll
backwards onto the driver when the loader is raised. Only lift loads
which can be contained in, and are intended for, the specific implement.
WARNING: The risk of overturn increases as the loader is raised. Be
extra careful on slopes when operating the loader. Always carry the
loader as low as practical for the conditions.
3. Operation
- 185 -
