• Select the PTO speed with the control lever.
The tractor has one of the following PTO speed range alternatives:
PTO speed ranges Lever position Function
540/1 000
PTO 540 activated
Centre PTO deactivated
PTO 1000 activated
1 000/540E
PTO 1000 activated
Centre PTO deactivated
PTO 540E activated
540/540E
PTO 540 activated
Centre PTO deactivated
PTO 540E activated
IMPORTANT: When using the speed 540E, the shaft speed of 540 rpm is
achieved with an engine speed of 1 539 rpm. If the engine speed is
accelerated, the power take-off (PTO) shaft speed can rise up to 800 rpm.
IMPORTANT: Do not exceed the maximum PTO speed of the implement
defined by the implement manufacturer.
The indicator light
flashes on the instrument panel when the rear PTO
has been activated. The light is lit continuously when the rear PTO is engaged.
• Activate the ground speed PTO (alternative equipment) by moving the lever
to the
position.
3.17.2.3 Starting rear power take-off
You can start the power take-off (PTO) after you have activated the PTO by
selecting the PTO speed with the speed control lever.
You can start the rear PTO in two ways:
• By using the PTO switch. The PTO switch is spring-returned and has three
positions: start/standby/off.
• By using the rear PTO on/off push button (extra equipment) on the rear
mudguard.
3. Operation
- 197 -
