GUID-3260AC5B-C12A-4EF0-A29E-41A57501D54E
1. Front power take-off speed
The PTO rotation speed is shown beside the symbol with an accuracy of 10 rpm.
3.10.3.4 Clock
The clock is displayed on the bottom row, either in 12-hour or 24-hour mode.
GUID-025B37DE-FB40-4B12-B2F1-F6290E50C5BF
1. Clock
You can change the time if it is not correct.
3.10.3.5 Gearbox temperature view
The gearbox temperature is shown on the top row of the display.
GUID-7B8278D4-942B-425F-8F91-56C9A988C6AA
1. Gearbox temperature
The gearbox temperature is displayed as follows:
• When the temperature is below +40°C (+104°F), the text "lo" is displayed.
• When the temperature is above +40°C (+104°F), the actual temperature is
displayed.
• When the temperature is above +119°C (+246°F), the text "high" is displayed.
NOTE: If the gearbox temperature is continuously above +90°C (+194°F), clean
the radiator and check the oil level.
3.10.3.6 Rear lower links' position view
The view shows the position of the rear lower links.
The position of the rear lower links
is shown on the top row of the display.
3. Operation
- 146 -
