Symbol Function
Gearbox temperature (C/F)
Lower link position (%, 0-100)
Periodical maintenance
3.10.3.1 Travel distance view
The travel distance is displayed in metres, kilometres, yards, or miles.
The travel distance is shown on the top row of the display.
GUID-EA131A29-8DD9-4071-9222-733D924CBBD3
1. Travel distance
The travel distance is displayed as follows:
• For distances <1 km (mile), the m (yard) symbol is displayed and the
distance is displayed with an accuracy of ±1 m (yard).
• For distances >1 km (mile), but ≤100 km (miles), the display symbol changes
to km (miles) and the distance is displayed with an accuracy of ±2 decimals.
• Distances >100 km (miles) are displayed with an accuracy of ±1 decimal.
• The maximum distance displayed is 999.9 km (miles).
If the driving trip unit (km / miles) needs to be changed, please contact an
authorised workshop.
3.10.3.2 Rear power take-off speed view
The rear power take-off (PTO) speed is shown in revolutions per minute (rpm).
The rear PTO speed
is shown on the top row of the display.
GUID-E4E172D2-FAF7-46FA-8EDF-284812D587BE
1. Rear power take-off speed
The PTO rotation speed is shown beside the symbol with an accuracy of 10 rpm.
3.10.3.3 Front power take-off speed view
The front power take-off (PTO) speed is shown in revolutions per minute (rpm).
The front PTO speed
is shown on the top row of the display.
3. Operation
- 145 -
