Automatic traction control symbol
The automatic traction control symbol blinks when automatic traction control is
activated. The symbol is displayed continuously when the desired direction has
been reselected.
Creeper speed range symbol
The creeper speed range symbol blinks when the creeper speed range is being
engaged. The symbol is displayed continuously when the creeper speed range is
engaged.
3.11.3 General information section
The general information section on the A-pillar display shows the basic mode
view. The information shown in the basic mode view changes according to the
driving situation. You can also select one of the views as fixed.
GUID-119624BC-53A6-4122-922D-796FF8E7DC08
1. Power take-off (PTO) symbol
2. Service code symbol
3. Low AdBlue level symbol
4. Thermometer symbol
5. Driving speed tractor symbol
6. Clock symbol
7. The value of the selected property
• In the basic mode view, the symbol for the rear PTO is shown only if the rear
PTO is rotating. If rear PTO is selected as fixed, also the rotating speed is
shown on the bottom line. The accuracy of the speed view is 10 rpm.
•
In the basic mode view, the symbol for the front PTO
is shown only if the
front PTO is rotating. If front PTO is selected as fixed, also the rotating speed
is shown on the bottom line. The accuracy of the speed view is 10 rpm.
If both the rear PTO and front PTO are rotating the rear PTO speed is shown.
• In the basic mode view, the thermometer symbol and the current outside
temperature are shown when the tractor is stationary. In the fixed view, they
are shown continuously. The accuracy of the temperature view is one
degree. The outside temperature sensor is placed in the front part of the
tractor. The engine temperature can falsely affect the thermometer,
especially when the tractor is stationary.
3. Operation
- 154 -
