4.7.5.12 Adjusting toe-in of front wheels
Adjust the toe-in of the front wheels if needed.
Before you adjust the toe-in, check that there is no free play in the ball joints of
the steering arms and tie rod.
NOTE: In order not to limit the steering movement, both tie rods must be adjusted.
1. Centre the wheels.
2. Loosen the tie rod locking nut.
GUID-B08F41DF-D557-4383-9D67-586ABE2C94CD
1. Locking nut
2. Adjustment screw
3. Turn the adjustment screw in the right direction.
4. Measure both tie rods.
IMPORTANT: Both tie rods must be of the same length after the adjustment.
5. Tighten the locking nut when the correct distance has been achieved.
6. Check the toe-in.
4.7.5.13 Changing the hydraulics breather
Change the hydraulics breather periodically.
IMPORTANT: If the tractor is used continuously in dusty conditions, the breather
must be changed more frequently.
4. Maintenance
- 290 -
