NOTE: The position of the lower links can be displayed on the instrument panel
display in the rear lower links' position view.
3.12.11 Activating and deactivating the draft control
GUID-D7E2700D-627D-44A6-9552-7FC2C4293637
1. Draft control selector
• To activate the draft control, turn the draft control selector from position P to
one of the eight levels.
• To deactivate the draft control, turn the selector to position P.
Turning the selector to the base position P ensures that the linkage is
controlled accurately by the position control knob.
3.12.12 Passing the position set by the position control knob
Use the passing switch for the position control knob when you temporarily need
the lower links to pass the lower limit set by the control knob. This feature is
useful for example when ploughing.
The passing switch for the position control knob allows a quicker entry of the
plough to the correct depth in the beginning and a better maintenance of the
depth at the end.
The passing switch for position control knob is spring returned and operates
when the lift/stop/lower switch is in the lower (Autocontrol) position.
When using the passing switch for position control knob, the lowering speed set
by the lowering speed selector is used.
3. Operation
- 163 -
