Valtra HiTech T3 Series User Manual

3.13.6.2 Adjusting pin-adjustable check links
1
GUID-E4F4874B-2E1E-4964-A436-5A9582FC62A9
1. Locking pin
1. Pull out the locking pin.
2. Adjust the length of the check link.
3. Put the locking pin back to lock the length of the link.
3.13.6.3 Using the floating position of automatic check links
1
2
GUID-0F9605D1-A348-47F5-8DFC-73A0939162EE
1. Holding chain
2. Link
• Adjust the length of the link’s holding chain.
Adjustment is done by changing the attachment point of the holding chain.
This adjustment defines the height of the lower links where the check links lock.
• Adjust the length of the check links to get the right amount of float.
3. Operation
- 177 -
