4.7.4.13 Changing front PTO housing oil and washing oil filter
Change the oil of the front power take-off (PTO) housing and wash the oil filter
regularly.
GUID-D3B6982A-BBCD-457E-B92A-B002A05CF282
1. End plate
2. Lock ring
3. O-ring
4. Filter
5. Oil level hole
6. Breather
7. Plug
1. Drain the oil by opening the plug at the rear of the housing.
2. Release the filter by loosening the lock ring and the end plate.
3. Clean the strainer with diesel.
4. Dry the strainer with compressed air.
5. Attach the filter and the parts in the contrary order.
Check that the O-ring fits the groove of the end plate.
6. Fill up the housing with oil to the level of the hole.
The breather can be loosened for bleeding. Check that the breather is not
blocked. When filling, the tractor has to stand on even ground.
7. Use the front PTO a moment and check oil.
4. Maintenance
- 275 -
