• Lower the implement to working position to allow floating.
• Lift the implement to transport position to lock the check links.
3.14 Auxiliary hydraulics
GUID-142F2FE4-E54C-491B-BDCB-ADFC702F4371
1. Rear valve 2
2. Rear valve 1
3. Rear valve 4 (extra equipment)
4. Rear valve 3 (extra equipment)
5. Return coupling
All the auxiliary hydraulics standard and extra equipment rear valves are
mechanically controlled.
The tractor is equipped with two valves with control lever as standard on the rear
side.
The tractor is equipped with an auxiliary hydraulic return coupling (1/2 inch).
Tractor can be equipped with two extra equipment valves with control lever on
the rear side. The following valves are available:
3. Operation
- 178 -
