15. Fit the locking pin.
CAUTION: Always fit the locking pin.
4.7.5.10 Greasing the flywheel ring gear
Grease the flywheel ring gear periodically.
GUID-95A332D9-083A-4D8E-A910-F2A2E634432B
1. Shield plug of the grease hole
1. Remove the shield plug of the grease hole on the clutch housing.
The grease hole is located on the left-hand side of the clutch housing.
2. Apply a little grease to a few points on the ring gear with a grease gun.
The grease spreads around the gear when the gear is used.
NOTE: Use Grease Moly.
4.7.5.11 Checking the front wheel toe-in
Check the front wheel toe-in periodically.
1. Make a vertical mark on both front tyres in the middle of the tread in level
with the hubs.
2. Measure the distance between the marks.
3. Roll the tractor forwards so that the marks again come in level with the hubs,
this time at the rear edge.
4. Measure the distance between the marks again.
The measurement must be 0-2 mm larger at the rear edge.
5. Adjust the toe-in if necessary.
4. Maintenance
- 289 -
