Tyres Industrial axle, track widths (mm)
Adjustable discs
14.9R28, 380/85R28, 420/70R28 1 530, 1 626, 1 732, 1 830
1)
, 1 928, 2 026, 2 130
16.9R28, 420/85R28, 480/65R28,
480/70R28
1 530, 1 626, 1 732, 1 830, 1 928
1)
, 2 026
540/65R28 1 530, 1 626, 1 732, 1 830, 1 928
1)
480/70R30, 520/60R28 1 535, 1 630, 1 740, 1 835, 1 935
1)
, 2 030
540/65R30, 600/65R28, 600/60R30 1 535, 1 630, 1 740, 1 835, 1 935
1)
230/95R36 1 500
1)
, 1 544, 1 812, 1 856, 1 898, 1 942, 2 210, 2 254
Fixed discs
400/80R28 IND, 420/85R28,
14.9R28, 14.9-28 FOR, 540/65R30,
540/65R30 IND, 540/70–30 FOR,
600/60R28
1 875
1)
, 1 900
16.9R28, 380/85R28, 540/65R28,
540/65R28 FOR, 440/80R28 IND,
16.9-28 FOR, 500/65R28 FOR
1 865
1)
, 1 890
1)
Standard track width
6.7 Engine
Model
T133 H T153 H T173 H T193 H
Designation 66 AWI 74 AWI
Type Four-stroke diesel engine with common rail direct injection
Turbocharged and intercooling Yes
Number of cylinders 6
Transport boost
1)
Yes Yes Yes Yes
Sigma Power
2)
No No No Yes
Max. output, kW/(hp)/rpm (ISO 14396)
Normal 104/(141)/2 000 114/(155)/2 000 132/(180)/2 000 140/(190)/2 000
Boost 116/(158)/2 000 125/(170)/2 000 140/(190)/2 000 155/(210)/2 000
Max. torque, Nm/rpm (ISO 14396)
Normal 580/1 500 640/1 500 660/1 500 680/1 500
Boost 630/1 500 680/1 500 730/1 500 800/1 500
Max. no load speed, rpm 2360
Low idling speed, rpm
Normal 850
Parking brake is on 650
1)
Higher transport boost power area when the main gear is H2 or higherThe driving speed
depends on the tyres used. For example with tyres 480/80R42, the transport boost is available
for speeds over 17 km/h.
2)
Sigma Power area, the largest output/torque area, when the power transferred through the
power take-off is large enough. The Sigma Power indicator light
is lit on the instrument
panel.
6. Technical specifications
- 347 -
