GUID-395E0FBB-ECB4-4C78-83B3-59B4375385BC
1. Lower links' position of the front linkage
3.9.3.11 Sigma Power view
The Sigma Power view shows the percentage of the maximum power that is
transferred through the power take-off (PTO).
The Sigma Power
is shown on the top or middle row of the display.
GUID-3A9F12C1-E00F-4B05-9D53-1A8108539BB3
1. Sigma Power
3.9.3.12 Gearbox temperature view
The gearbox temperature is shown on the top or middle row of the display.
GUID-15ED75B0-390B-447E-9DB7-B66BD066538C
1. Gearbox temperature
The gearbox temperature is displayed as follows:
• When the temperature is below +40°C (+104°F), the text "lo" is displayed.
• When the temperature is above +40°C (+104°F), the actual temperature is
displayed.
• When the temperature is above +119°C (+246°F), the text "high" is displayed.
NOTE: If the gearbox temperature is continuously above +90°C (+194°F), clean
the radiator and check the oil level.
3. Operation
- 133 -
