3. On the left side, remove the lowest step completely by unscrewing three
screws.
1
GUID-B9481B13-0E49-4E2C-B31D-C63A3AE341A7
1. Screws
4.8.9.2 Limiting the door opening
Limit the door opening when on twin wheels.
2
1
GUID-26E5254C-769C-4408-B110-7BC1F79E3562
1. Gas spring
2. Fastening holes
• Check that the door does not come in contact with the wheels when
mounting twin wheels.
• Change the gas spring to another hole if needed.
4.8.9.3 Checking and adjusting front mudguards
Check and adjust the front mudguards if needed.
• After transportation, check and adjust the front mudguards for maximum
turning angle.
• If necessary, move them to the right width so that the mudguards do not
touch the tractor chassis.
The minimum distance of the mudguards frame from the tyres is 40 mm
sideways and 60 mm vertically.
4. Maintenance
- 322 -
