3. The service codes start to scroll on the display in four parts.
For example, the code 000091-13-035 is displayed in the following order.
GUID-0F74E701-8C1D-4B75-9582-6E71A1A07DA6
• 0000
• 0091
• 0013
• 0035
The service code order number shows which code is currently scrolling on
the display. The service code part indicator shows which part of the code is
displayed on the service code value field.
4. Exit the service code list.
To exit the service code view, push the pre-programming push button, the
Powershift button or the HiShift button.
5.5 Service codes
Service codes indicate different errors in the tractor components or functions.
IMPORTANT: The table explains what the service codes mean and what
measures you should take in these situations.
NOTE: If two or more service codes marked with a star (*) are displayed
simultaneously, driving is prevented for safety reasons until the error situations
have been repaired.
5. Faults and remedial actions
- 333 -
