GUID-A3BD895F-8759-43F0-9780-CA19C820A36A
1. Air filter housing
2. Ventilation air filter
1. Remove the air filter housing from the upper left-hand corner of the cab roof.
• Pull down from the handle.
• Turn the handle counterclockwise.
The turning direction is instructed on the handle.
2. Remove the ventilation air filter.
3. Check the condition of the ventilation air filter.
A damaged ventilation air filter must be changed.
4. Clean the ventilation air filter.
• Knock the filter element against your palm so that most of the dirt comes
off.
• Use a vacuum cleaner to clean the ventilation air filter from the outside in
or blow it clean with compressed air from the center outwards.
IMPORTANT: Make sure that the air pressure is not too high.
A larger air filter housing with active coal filter or larger air filter is available as
extra equipment.
4.7.4.5 Checking the brake pedal free travel
Check the brake pedal free travel periodically.
GUID-EF67E40A-0816-4DDA-A5CF-C324AF720D99
1. Free travel of the pedal
4. Maintenance
- 267 -
