Indicator light Indication
GUID-
F0C90BFB-3126-404D-8C49-3FA955C
C4FD2
Parking brake indicator light
The light (red) is lit to indicate that the power shuttle lever is in the parking brake position.
GUID-714DD8B7-ED71-4AA7-
BFAA-31C5E3693067
Low fuel level indicator light
The light is lit (yellow) and a buzzer sounds once to indicate that about 50 litres of fuel
is left.
GUID-CD4C4C77-7CDB-4FB5-AF3A-
BEFDF3417EB1
Battery charging indicator light
2.2.1.3 Indicator lights on the right side of the display
GUID-57051FB5-C513-443B-A2FE-1E7ADF0A7DA9
Indicator light Indication
STOP indicator light (red)
GUID-9B9A9C87-
BB4C-43A1-9A88-789929
9F22D0
Gearbox oil pressure light (red)
GUID-
AC890C72-21FE-4056-89
5A-DB34A4CE9357
Gearbox oil temperature light (red)
GUID-9B16B673-
D692-4975-
A9F9-5D6DBAFC4177
Hydraulic pressure and auxiliary return oil filter clogging indicator light (red)
GUID-1E59203D-
F3B7-420D-ABC9-
F7433B7A6C19
Front wheel drive indicator light
The light is lit (yellow) to indicate that front wheel drive is engaged.
GUID-9AA1D60E-5812-4
B9F-
BDB0-44D48BEA8941
Front power take-off (PTO) indicator light
The light (yellow) is continuously on and indicates that the front PTO is engaged.
GUID-533CED2D-
D3E0-4488-8590-
A1E859BA91C5
Differential lock indicator light
The light is lit (yellow) to indicate that the differential lock is engaged.
GUID-70C6E3BD-
C691-4819-BA77-
BA56A2A6A231
Rear PTO indicator light
The light blinks (yellow) when the rear PTO has been activated and is ready to operate.The
light is on continuously when the rear PTO is engaged.
2. Instruments and controls
- 28 -
