3.2.5 Adjusting standard mirrors
You can adjust the position of the standard mirrors manually.
GUID-94073A8E-5075-4F2D-A9E9-581B1312B9E4
1. Locking device of the mirror support
1. Loosen the locking device of the mirror support.
2. Adjust the mirror position.
3. Tighten the locking device.
3.2.6 Adjusting optional mirrors
You can adjust the position of the optional mirrors electrically.
GUID-8BA97365-1C8D-43C9-96A2-10A4AA230C0F
1. Mirror adjustment
• To adjust the left mirror, turn the knob to the left and push the knob in the
direction of the arrows.
• To adjust the right mirror, turn the knob to the right and push the knob in the
direction of the arrows.
3. Operation
