Tyre Parameter value for T173
H-193 H, with 40 km/h
Parameter value for T153
H, and for T173 H-T193 H
with 50 km/h
650/65R38 FOR 184 166
650/65R38 GY 183 166
650/65R38 M 185 168
650/65R42 175 159
650/75R38 174 158
680/75R32 M 184 167
4.8.2 Track widths
The track width is measured between the middle of the tyres. If needed, adjust
the track widths.
IMPORTANT: The maximum allowed width of the tractor is 2550 mm (if larger
width is not nationally allowed).
The distance between the mudguards is 1090 mm at the rear.
In many work applications, it is advisable to adjust the track widths so that the
track made by the front tyres is covered by the track made by the rear tyres.
When using narrow track widths for the rear axle, check that the lower links do
not touch the tyres. When required, lock the side regulators.
IMPORTANT: According to EU directives the smallest allowed distance between
the tyre and the cab is 40 mm.
4.8.2.1 Agricultural front axle track widths
The agricultural front axle track widths (in mm) are listed in the following table.
380/85R28,
14.9R28
2 135 2 045 1 930 1 840 1 735 1 645 1 530
16.9R28,
420/70R28,
420/85R28,
440/65R28,
480/65R28,
480/70R28
2 045 1 930 1 840 1 735 1 645 1 530
Table continued on next page
4. Maintenance
- 308 -
