Valtra HiTech T3 Series User Manual

2
1
GUID-3A495A70-9F56-4273-8001-7254707A4C47
1. 224 mm
2. T measure
6.9.5.5 Proportional ground speed
Model Power take-off (PTO) axle rpm/1 rear wheel rpm
T133 H, 40 km/h 40.81
T153 H-T193 H, 40 km/h 41.03
T153 H-T193 H, 50 km/h 40.79
6.9.6 Front power take-off
Oil type
Oil volume (litres)
Shell Donax TX 2
6.9.6.1 Front power take-off ratios
Front power take-off (PTO) ratio
1 000 rpm at engine speed 1 920 rpm
6.9.6.2 Front power take-off shafts
Splines
Standard Shaft diameter (mm)
6 ISO 500 35
6.10 Brake system
Operation • Hydraulically controlled multi-
disc type brakes with wet discs
• Boosted with low pressure
hydraulic
• Two brake cylinders
• No separate brake fluid
• Pressure accumulator to
ensure the pressure
• Oil spray cooling of the friction
disc elements when necessary.
• Hydraulically controlled multi-
disc type brakes with wet discs
• Boosted with low pressure
hydraulic
• Two brake cylinders
• No separate brake fluid
• Pressure accumulator to
ensure the pressure
• Oil spray cooling of the friction
disc elements when necessary.
Number of brake friction discs 5 pcs/side 5 pcs/side
Friction disc diameter 224 mm 242.5 mm
Brake friction area
3690 cm
2
/org. 4 272 cm
2
/org.
Brake pedal free travel 45–55 mm 35-45 mm
6. Technical specifications
- 352 -
